Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0
Photosocket Relay E27 Smart X-Control 2.0

Information

Technical Specifications

  • Voltage: 100~240V;
  • Operating frequency: 50/60Hz;
  • Power consumption: <0.4W;
  • Technology: Microprocessor-controlled and comes pre-configured from the factory. Its functions can be altered using Smart X-Control technology, configured via the Smart X-Control app;
  • Configuração de fábrica: Tempo: automático, Fotocélula: mínima e Função Random: desativada;
  • Components: plastics, electronics, and metal alloys;
  • Insensitive to sudden changes in brightness (headlights, lightning, laser pointers, etc.);
  • Timer function: Automatic, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 hours;
  • Automatic function (AUTO): turns the light on when it gets dark and turns it off automatically when there is natural light;
  • It has a red LED to confirm successful recording of the configured parameters;
  • Photocell setting: Minimum (at night) to Maximum (at dusk);
  • Random function: turns the light on and off randomly in the absence of natural light, varying between 10 minutes and 3 hours and 40 minutes.
  • Reset function: Returns the product settings to factory defaults;
  • Lamp-friendly: load activation system with low electrical voltage <50V, increasing the lifespan of the assembly (lamps, ballast and sensor);
  • Exclusive intelligent light learning system: prevents the flickering effect;
  • Electrical connection: Directly into the E27 socket of the light bulbs;
  • It features a unique 340º rotating base, allowing you to direct the photocell window towards the side with the greatest incidence of natural sunlight for optimal performance;
  • Operating temperature: -5°C to +40°C;
  • Protection rating: IP30 (should not be installed in locations exposed to rain or moisture);
  • Warranty: 2 years;
  • Dimensions: Ø49.3×82.1mm;
  • Control power:
Voltage Lamp position Electronics/LED/Halogen
127/220V~ Upside down or horizontal 60W
Virada para baixo 40W
THD<20% and FP>0.90

Installation

There is no need to open the relay or use tools to program it. To install the photocell relay, simply screw it into an E27 socket. Then, direct the photocell towards the location with the highest incidence of natural light.

Photosocket Relay E27 Smart X-Control 2.0

available

Code: FTS0MPXC2BC

Description

Automatic and intelligent lighting without complications. The Smart X-Control Photosocket Relay turns the light on at dusk and off at dawn. Want more? Easily customize everything with the Smart X-Control app on your phone. Install in minutes and enjoy greater comfort and safety.

Download

Packaging

User manual

R$ 28,58

Shipped within 7 business days.
Price* for end consumer

Information

Technical Specifications

  • Voltage: 100~240V;
  • Operating frequency: 50/60Hz;
  • Power consumption: <0.4W;
  • Technology: Microprocessor-controlled and comes pre-configured from the factory. Its functions can be altered using Smart X-Control technology, configured via the Smart X-Control app;
  • Configuração de fábrica: Tempo: automático, Fotocélula: mínima e Função Random: desativada;
  • Components: plastics, electronics, and metal alloys;
  • Insensitive to sudden changes in brightness (headlights, lightning, laser pointers, etc.);
  • Timer function: Automatic, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 hours;
  • Automatic function (AUTO): turns the light on when it gets dark and turns it off automatically when there is natural light;
  • It has a red LED to confirm successful recording of the configured parameters;
  • Photocell setting: Minimum (at night) to Maximum (at dusk);
  • Random function: turns the light on and off randomly in the absence of natural light, varying between 10 minutes and 3 hours and 40 minutes.
  • Reset function: Returns the product settings to factory defaults;
  • Lamp-friendly: load activation system with low electrical voltage <50V, increasing the lifespan of the assembly (lamps, ballast and sensor);
  • Exclusive intelligent light learning system: prevents the flickering effect;
  • Electrical connection: Directly into the E27 socket of the light bulbs;
  • It features a unique 340º rotating base, allowing you to direct the photocell window towards the side with the greatest incidence of natural sunlight for optimal performance;
  • Operating temperature: -5°C to +40°C;
  • Protection rating: IP30 (should not be installed in locations exposed to rain or moisture);
  • Warranty: 2 years;
  • Dimensions: Ø49.3×82.1mm;
  • Control power:
Voltage Lamp position Electronics/LED/Halogen
127/220V~ Upside down or horizontal 60W
Virada para baixo 40W
THD<20% and FP>0.90

Installation

There is no need to open the relay or use tools to program it. To install the photocell relay, simply screw it into an E27 socket. Then, direct the photocell towards the location with the highest incidence of natural light.
